Robot Mower Setup: Base Station, Antenna and Mapping

The most useful bullet in a listing is often the last one. The Navimow i105N record lists a charging station, a power supply, an extension cable with pegs, a GNSS antenna kit with its own installation kit and spare blades. The LUBA 2 AWD 3000X record lists a charging station, an RTK installation kit and a spare blade set. The YARBO Y40 Core record warns that it ships in four boxes, weighs roughly 210 pounds and recommends two adults for assembly.

Those lists tell you what arrives, and by omission what does not. A model that ships an antenna kit needs a place to mount it; a model that ships nothing of the kind may rely on network corrections or cameras. Compare package lists across the exact ASINs you are considering, because a garage bundle or a stand bundle may add or remove items. Our buying guide puts the package list next to the lawn measurements for that reason.

The station needs a weatherproof outdoor outlet within reach of its supplied cable, level ground, protection from sprinklers and a straight approach the mower can use to dock. Manuals specify minimum clearances in front and to the sides and often a maximum slope at the station. We do not repeat those numbers here because they differ by model and revision; read the current manual for the exact product. Photographs in listings and our own editorial illustrations are compositions, not approved layouts.

Think about the return route as well as the parking spot. A station at the far end of a narrow passage means every charge cycle crosses that passage twice. Where the lawn is split into zones, the station location determines how much of each charge is spent traveling. The capacity guide explains why that travel erodes the effective coverage of a stated capacity.

RTK models need a reference antenna with a wide, unobstructed view of the sky. The YARBO record states the requirement plainly: a 120-degree unobstructed view for its data center set. Other listings sell wall or pole mounts separately, and the accessory category on this site includes several antenna mounts named for specific mower families. Identify a candidate spot, look up from it and note roofs, mature trees and neighboring buildings. Then confirm the manual's requirement for the exact model.

If no spot on the property offers that view, that is a decision point, not a detail. Some sellers describe network RTK over a data connection, some describe vision or LiDAR fallback, and some products avoid satellites altogether. The navigation guide explains what each approach requires. A listing's claim that the mower works under trees is a seller statement about its fallback, and the manual will describe the conditions behind it.

Wire-free models are mapped by driving or walking the mower around the perimeter and each island in the app. The Navimow i215 record describes one-tap auto mapping and up to twenty editable zones; other records describe assisted mapping or drop-and-mow modes without a map. Whatever the method, budget time for it, and expect to refine edges after the first passes. Manuals also state a maximum grass height before the first mowing; several listings repeat it. Cut the lawn conventionally first if it is above that height.

Boundary-wire models replace mapping with wire laying, described in the boundary comparison. In both cases, test the full route in daylight while you can intervene, watch the transitions at passages and slopes, and confirm the mower docks on its own before you rely on a schedule. Nothing in a listing establishes that a first run will be uneventful.

Most current models are configured entirely through an app, which means a phone, an account, and either Wi-Fi reaching the lawn or a cellular module. Listings differ on whether 4G is included, optional or subscription-based; the Navimow record calls its anti-theft 4G module an optional add-on, while several LUBA records include 4G in the title. Check the current requirements for the exact model, because app features and regional availability change with software updates.

Also verify what happens without connectivity: whether the mower keeps a schedule, whether the map is stored locally, and how you stop it in an emergency. Those are operating questions for the manual and the manufacturer, not for a review score. Our comparison pages list review-backed candidates under a published formula that does not evaluate app quality or connectivity reliability.
